Product Details:
Payment & Shipping Terms:
|
Power: | 150W | LED Chip: | Lumileds 5050 SMD |
---|---|---|---|
LED Driver: | Meanwell HLG-150 | IP Rating: | IP65 |
CCT: | 2700-6500K | Warranty: | 5 Years |
Beam Angle: | 150X65degree | Package: | 75cm×40cm×23cm (2 PCS ) |
GW: | 9.6kg | Luminous Flux: | 24000lm |
Dimmable: | YES&NO | CRI: | >80 |
Pole Diameter: | 60mm | ||
High Light: | led roadway lighting,led street lamp |
IP65 LED Road lighting , Energy Efficient Street Lighting CE Rohs CB Certifications
Part Number | LY-ST20150-XX |
Power | 150W |
Luminous flux | 24000lm |
Light efficiency | 160lm/W |
Light source | Lumileds Luxeon 5050 |
Material | High quality die-casting aluminum alloy |
Light degradation rate | 25000h ≤ 30% |
Color rendering index | Ra≥80 |
Power Factor | PF≥0.98 |
Brand Of Driver | Meanwell Driver |
Life time | ≥50000hours |
Color temperature | 2700K-6500K |
Working temperature | -30~+50°C |
Input Voltage | AC90-260V |
Beam angle | 150*65 degree |
IP grade | IP66 waterproof |
Product Brand | LEYOND(OEM.ODM available) |
Warranty | 5 years |
Certificate | ROHS, EMC, LVD,CB |
Application | Parking lot, garden, courtyard, road, outdoor, etc. |
LUXEON 5050:
LUXEON 5050 is a multi-die, high power package that provides high luminance from a single package to enable cost effective, single optic and directional fixture designs. LUXEON 5050 uses an industry standa rd 5050 surface mount package with the smallest round Light Emitting Surface (LES). LUXEON 5050 comes in 70CRI, 80CRI and 90CRI with a wide range of CCTs, and offers hot-color targeting to ensure that the LEDs are within color target at application conditions of 85°C.
Voltage |
Nominal
|
Minimum
|
LUMINOUS FLUX(lm) |
TYPICAL LUMINOUS EFFICACY (LM/W) |
TESTCURRENT
|
PART NUMBER |
|
---|---|---|---|---|---|---|---|
MINIMUM |
TYPICAL |
||||||
24V |
2700K |
70 |
535 |
575 |
147 |
160 |
L150-2770502400000 |
3000K |
70 |
553 |
595 |
152 |
160 |
L150-3070502400000 |
|
4000K |
70 |
580 |
625 |
159 |
160 |
L150-4070502400000 |
|
5000K |
70 |
580 |
625 |
159 |
160 |
L150-5070502400000 |
|
5700k |
70 |
570 |
615 |
157 |
160 |
L150-5770502400000 |
|
6500K |
70 |
570 |
615 |
157 |
160 |
L150-6570502400000 |
|
2700K |
80 |
500 |
535 |
136 |
160 |
L150-2780502400000 |
|
3000K |
80 |
516 |
555 |
142 |
160 |
L150-3080502400000 |
|
3500K |
80 |
527 |
567 |
145 |
150 |
L150-3580502400000 |
|
4000K |
80 |
539 |
580 |
148 |
160 |
L150-4080502400000 |
|
5000K |
80 |
539 |
580 |
148 |
160 |
L150-5080502400000 |
|
6500K |
80 |
539 |
580 |
148 |
160 |
L150-6580502400000 |
|
2700K |
90 |
414 |
445 |
114 |
160 |
L150-2790502400000 |
|
3000K |
90 |
428 |
460 |
117 |
160 |
L150-3090502400000 |
|
3500K |
90 |
445 |
480 |
122 |
160 |
L150-3590502400000 |
|
4000K |
90 |
456 |
490 |
125 |
160 |
L150-4090502400000 |
|
6V |
2700K |
70 |
535 |
575 |
147 |
640 |
L150-27700500600000 |
3000K |
70 |
553 |
595 |
152 |
640 |
L150-3070500600000 |
|
4000K |
70 |
580 |
625 |
159 |
640 |
L150-4070500600000 |
|
5000K |
70 |
580 |
625 |
159 |
640 |
L150-5070500600000 |
|
5700K |
70 |
570 |
615 |
157 |
640 |
L150-5770500600000 |
|
6500K |
70 |
570 |
615 |
157 |
640 |
L150-6570500600000 |
|
2700K |
80 |
500 |
535 |
136 |
640 |
L150-2780500600000 |
|
3000K |
80 |
516 |
555 |
142 |
640 |
L150-3080500600000 |
|
3500K |
80 |
527 |
567 |
145 |
640 |
L150-3580500600000 |
|
4000K |
80 |
539 |
580 |
148 |
640 |
L150-4080500600000 |
|
5000K |
80 |
539 |
580 |
148 |
640 |
L150-5080500600000 |
|
6500K |
80 |
539 |
580 |
148 |
640 |
L150-6580500600000 |
|
2700K |
90 |
414 |
445 |
114 |
640 |
L150-2790500600000 |
|
3000K |
90 |
428 |
460 |
117 |
640 |
L150-3090500600000 |
|
3500K |
90 |
445 |
480 |
122 |
640 |
L150-3590500600000 |
|
4000K |
90 |
456 |
490 |
125 |
640 |
L150-4090500600000 |
Product Description:
led street lighting series
Model | Power | Lumens | LED Chip | Driver | Input Voltage |
LY-ST20030-XX | 30W | 3600lm | 30pcs Lumileds 3030 | Meanwell HLG-40 | AC95-305V |
LY-ST20040-XX | 40W | 4800lm | 30pcs Lumileds 3030 | Meanwell HLG-40 | AC95-305V |
LY-ST20050-XX | 50W | 6000lm | 30pcs Lumileds 3030 | Meanwell HLG-60 | AC95-305V |
LY-ST20060-XX | 60W | 7200lm | 30pcs Lumileds 3030 | Meanwell HLG-60 | AC95-305V |
LY-ST20100-XX | 100W | 12000lm | 90pcs Lumileds 3030 | Meanwell HLG-100 | AC95-305V |
LY-ST20120-XX | 120W | 14400lm | 90pcs Lumileds 3030 | Meanwell HLG-120 | AC95-305V |
LY-ST20150-XX | 150W | 18000lm | 90pcs Lumileds 3030 | Meanwell HLG-150 | AC95-305V |
LY-ST10030-XX | 30W | 4800lm | 30pcs Lumileds 5050 | Meanwell HLG-40 | AC95-305V |
LY-ST10040-XX | 40W | 6400lm | 30pcs Lumileds 5050 | Meanwell HLG-40 | AC95-305V |
LY-ST10050-XX | 50W | 8000lm | 30pcs Lumileds 5050 | Meanwell HLG-60 | AC95-305V |
LY-ST10060-XX | 60W | 9600lm | 30pcs Lumileds 5050 | Meanwell HLG-60 | AC95-305V |
LY-ST10100-XX | 100W | 16000lm | 72pcs Lumileds 5050 | Meanwell HLG-100 | AC95-305V |
LY-ST10120-XX | 120W | 19200lm | 72pcs Lumileds 5050 | Meanwell HLG-120 | AC95-305V |
LY-ST10150-XX | 150W | 24000lm | 72pcs Lumileds 5050 | Meanwell HLG-150 | AC95-305V |
Quality Warranty:
Quality guarantee is based on storing,installing,operating and maintaining correctly in the normal operation condition.
It is not included in our maintaining range when installing inappropriately,breaking the operating rules,and leading to the products damaging.
Our company will maintain the right to either repair,parts replacing,or products exchange during the quality warranty period.
