Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

China Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W supplier
Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W supplier Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W supplier Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W supplier Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W supplier

Large Image :  Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

Product Details:

Place of Origin: China
Brand Name: LEYOND
Certification: EMC,LVD, RoHS
Model Number: LY-ST30240-XX

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiatable
Packaging Details: Standard Plain Carton Package
Delivery Time: 7-15 working days
Payment Terms: T/T, Paypal, Western Union, MoneyGram
Supply Ability: 10,000pcs/month
Contact Now
Detailed Product Description
Material: Aluminum+PC Cover Chip Brand: Luxeon 5050
Driver Brand: Meanwell Warranty: 5 Years
Luminous Efficiency: 160LM/W-180LM/W CRI: >80
IP Grade: IP66 Beam Angle: 25/60/90 Degree

240w Modular LED Stadium Light Lumileds 5050 Chips Meanwell driver 160LM/W-180LM/W


1. Features:



1. Adoption LEYOND exclusive Lens with light transmittance up to 98%.



2. There are 25°,60°, 90° beam angle options for the Lens.



3. High luminous efficiency,Whole lamp output light effiency >160LM/W.



4. Die-cast aluminum with Good heat dissipation



5. World top class Meanwell Driver, 5 years warranty



6. IP66 waterproof design for outdoor application.



2. Advantages:

1) Luxeon 5050 chips inside,160-170lm/w, plus Meanwell driver.
2) Independent model design,Viewing angle: 25°/60°/90°, IP66 rated.
3) Available for Daylight sensor,5 years warranty.



3.  Technical parameter:


Model modules number Power Input Voltage Input Current Power factor Power efficiency
LY-ST30240-PW             5  240W   AC90~305V
    50/60Hz
1.86A/220VAC   >0.95           >90%



Photometric Specifications:

Par NO

Parameter

LY-ST30200XX LY-ST30240XX
Input voltage AC100V~240V 50/60HZ
System consumption(W) 200 240
Luminous flux(lm) 33000 38400
Chip Brand

LUXEON 5050

LEYOND 5050

LUXEON 5050

LEYOND 5050

Beam Angle 25°,60°, 90° 25°,60°, 90°
Current 0.96A/220V 1.15A/220V
Color Temperature WW:2700-3200K / NW:4000-4500K / PW:5000-6500K
CRI >75
Luminous efficiency(lm/w) >160
Lifespan(hrs) >50000
IP Rating IP66
Dimmable YES&NO YES&NO
Size(mm) 540*340*67 540*340*67
Net Weigh(kg) 9.5 9.5



Model modules number Power Luminous flux Luminous  efficiency CRI CCT BeamAngle
LY-ST30240PW           5 240W        38400lm       160lm/W   >80

3000K
4000K  4500K
5000K  5700K

6000K


35°
60°

90°
  1. Mechanical Specifications:
Model modules number Power    Carton Size gross weight Net Weight IP Rating Meterial
LY-ST302400PW          5 240W 540X340X67MM      12kg    10.5kg    IP66 Aluminum +PC


Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

Factory Sale Modular LED Stadium Light Lumileds 5050 Chips Meanwell Driver 160LM/W

Application:

It is applicable to playground lighting ,stadium lighting,plaza lighting, and so on.

New Installation or Replace the traditional High Pressure Sodium Lamp, High Pressure Mercury Lamp, and Metal Halide Street Lamps. Etc.



Welcome to contact us for more details.
