MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control

Certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
Customer Reviews
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control
MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control

Large Image :  MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control

Product Details:

Place of Origin: Guangdong, China
Brand Name: LEYOND
Certification: TUV, CE, RoHS, CB, ENEC, GS, SAA, UL, DLC, FCC, SASO
Model Number: LY-ST70100PW

Payment & Shipping Terms:

Minimum Order Quantity: 2pcs
Price: 160$-380$ based on your power request, quantity
Packaging Details: Neutral Export Packing, each lamp with an individual inner carton, 2 inner cartons load into 1 outer carton
Delivery Time: 7-10 days
Supply Ability: 60000 pcs / month
Detailed Product Description
Power: 100w LED Chip: Lumileds 5050
Battery: Phosphate Lithium Battery 12V 100 Ah IP Rating: 66
CCT: 3000K / 4000K / 5000K / 6000K CRI: Ra>70
Beam Angle: 150x65 Degree Solar Panel: Mono-crystalline Silicon
Sensor: Microwave Motion Sensor Working Time: A Full Loaded Battery Could Work 5-7 Nights
Efficiency: 165lm/w Controller: MPPT
Working Tem: -40-55 Degree Celsius Application: Landscape / Rural Road / Park / Path / Parking Lot
Lead Time: 7-10 Days Warranty: 3 Years
Life Span: 2000 Times Recycle
High Light:

IP66 Solar LED Street Light 100w

,

TUV 100W Solar LED Street Light

,

MPPT 100 Watt Solar Street Light

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control



100w Off Grid All In 2 Mono-Crystalline Time Control Solar LED Street Light



Features:



Integrated design, off grid design, wireless for fitting, the installation is very convenient.



Mono-crystalline solar panel,LED lights,lithium battery,intelligent controller integrated Aluminum Alloy shell.



• Adopt lithium iron phosphate battery, fight the high temperature, keep long lifespan.



When the products with optically controlled microwave induction infrared sensor, automatic adjustment of intelligent power on rainy days, extend rainy days.



Adopt alloy material as the main structure,with good rust prevention,corrosion protection.



The wireless remote control setting device, adjustable lighting time, lighting power, automatically detection of battery voltage, read light power parameters, a human body induction function, as long as people go through when full power lighting, no automatic power down alf, restore energy saving mode.



Time control + motion sensor control



Brightness of the proximity sensor registers walker: Full power 100%; Walker left 10 seconds transform into smart mode; Brightness of Smart mode: 10%



If other brightness request, lighting period & brightness programmable.



Specification:



Par NO.
Parameter LY-ST70100PW LY- ST70100NW LY- ST70100WW
Battery 18650 lithium battery 12V 100 Ah
Beam angle 150x65°
Pole diameter 60MM
Light output 100W
Luminous flux(lm) 16500
LED Quantity(pcs) 96
Color Temperature Pure white:5000-6500K Warm white:4000-4500K Neutral white:2700-3200K
Solar panel 120W /18V monocrystalline silicon
CRI 70
Chip Brand LUXEON 5050
Operating time A full loaded battery works 5-8 nights
Control Mode Light Control +Time Control
Material Die Casting Aluminum
Luminous efficiency(lm/w) 160
Lifespan(h) 50000
IP Rating IP66
Installation height

6-10M





Product descreption:



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 0

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 1

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 2

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 3



Installation method:



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 4



Application cases:



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 5

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 6

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 7

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 8

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 9



Installation instructions:

1. Switch off the Switch button

2. Adjust the right angle of the lamp

3. Connect the lamp adapter to Pole

4. Electrical wiring connection if Hybrid kit needed

5. Tight the adapter screws

6. Switch ON



Oprations:

• Operation Ambient Temperature -25 to +50°C, Relative Humidity 20~90%

• Input Voltage 100~240V AC, 50/60Hz

• Storage Ambient Temperature -40 to +55°C, Relative Humidity 5~95%

• Mounting Height : Suitable for 3~6m height



(Kindly reminder: All installation steps must handl by professional electrician)



Distribution Curve:



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 10



Applications:



- Parking lot

- Park

- Patio

- Rural road

- Landscape

- Walkway

- Path



Package info:



Lighting Fixture package

Inner box Size: 453mm×270mm×200mm

Outer box Size: 470mm×285mm×425mm

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 11

Solar Panel package

Inner box Size: 1055mm×180mm×725mm

Outer box Size: 1070mm×375mm×740mm

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 12

Actual pictures:



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 13

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 14

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 15

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 16



Related hot selling products:

MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 17

1. Sword series LED street light 130w-200w
2. Sword series LED street light 70w-120w
3. Sword series LED street light 20w-60w
4. King series LED street light 80w-200w
5. King series LED street light 20w-60w
6. Integrated All in one Solar LED garden light 40w-100w
7. Integrated All in one Solar LED garden light 10w-30w
8. Fairy LED street light 10w-30w
9. Galaxy series LED street light 30-100w
10. Galaxy series LED street light 110w-200w



MPPT 100w IP66 Solar LED Street Light Mono Crystalline Time Control 18





Mr. Pure Zhao (Sales Engineer)
Shenzhen Leyond Lighting Co.,ltd
Web: www.leyond.com.cn
Email: sales15@leyond.com.cn

Mobile/whatsapp: 0086 18675501972
Wechat: 0086 18675501972





FAQ:



- What about the lead time?

A:Sample needs 7 days, mass production time needs 1-2 weeks for order quantity more than



- Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available



- How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



- How to proceed an order for led light?

A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.



- Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



- Do you offer guarantee for the products?

A: Yes, we offer 5 years warranty to our products.



- How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
