Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving

Good quality High Power LED Flood Light for sales
Good quality High Power LED Flood Light for sales
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving

China Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving supplier
Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving supplier Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving supplier Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving supplier Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving supplier

Large Image :  Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving

Product Details:

Place of Origin: China
Brand Name: Leyond
Certification: CE RoHS
Model Number: LY - HB35100

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: 3pcs/ctn
Delivery Time: 7-10 working days
Payment Terms: T/T, Paypal
Supply Ability: 3000pcs per month
Contact Now
Detailed Product Description
Item: LED UFO High Bay Lamp Power: 100W
Inptut Voltage: AC100V ~ 240V 50 / 60HZ LED Driver: Meanwell HLG
Bean Angle: 120° CRI: >80
Warranty: 5 Years Warranty Lamp Driver: Or Meanwell

 160 lumen per watt high bright Factory Warehouse LED high bay light

Why choose UFO High Bay?



1. ) High brightness , 160lm/w



2. ) A new and comprtitive price with a cost saving of 20 % than others HighBay



3. ) SMD3030 , has excellent scattered heat emission and a low light decay



4. ) No seperately difusser compared with traditional high bay , save more space and shipping cost

  • Technical parameter

Par NO  Parameter

LY-HB35100WW LY-HB35100NW LY-HB35100PW
Inptut voltage AC100V~240V 50/60HZ
Sysem consumption(W) ≤102 ≤102 ≤102
Light Fixture Luminance(lm) 10900 11600 12100
LED type SMD3030 SMD3030 SMD3030
LED QTY 120 120 120
System Efficiency >90% >90% >90%
Driver / MEAN WELL
Beam Angle 120° 120° 120°
CRI >80 >80 >80
Color Temperature(CREE) 2700-3200k 4000-4500k 5000-6500k
Meterial Magnesium Aluminum + PC cover
Lifespan(hrs) >50000
IP Rating IP65
Product Size(mm) Φ340X162 Φ340X162 Φ340X162
NET Weight(KG) 3.6 3.6 3.6

  • Distribution Curve

Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving



Facture



Up to 80% Energy-saving compared to metal halide lamp , mercury-free and 100% recyclable,

energy saving and environmental protection



Isolated internal led driver , easy installation , safety guaranteed



High PF value 0.9 above and THD less 15% for decrease of electricity loss



Up to120LM/W high light efficacy , 50000h above lifespan , 5 Years warranty , cost effective



Power supply key components adopt world brand , No flicker , no delay , Instant on / off



Designed for hook type , can be directly replaced is used to quick and easy



Installation to minimize retrofit and maintenance costs



Small size , less weight and durable is the best choice for warehouses , stadiums , exhibition spaces , high ceiling lights.



Using imported chip , LED encapsulation structure optimization , to achieve low light failure , high photosynthetic efficiency , energy conservation and environmental protection advantages.







Application



There is widely used in Warehouse , Industrial workshops , Logistics centers , Exhibition halls , Stadiums , Docks , Golf courses , Airport , Highway toll stations , supermarkets Light engineering.



Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving





Package



  • Carton Size: 370mm×370mm×180mm
  • Net weight:3.6KG Gross weight:4.5KG



Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving







Assembly and Installation



  • Assembly Electricity

Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving

  1. Blue : Neutral
  2. Brown : Line
  3. Yellow-Green : Ground



  • Installation



Step1. Ensure all power disconnected and turn off the power switch.



Step2. Knowing the inside diameter of the circular ring,then choose suitable hook for the lamp.



Step3. Fix the hook before installation and enable it to support over 3 times weight of the lamp. Connect the lamp with hook and make it safe.



Step4. Connect the input cables of lamp to power supply mains and wrap up the cables with insulated sleeve.



Step5. Switch on the power, the lamp will light on. Refer to the left figure.



In case of any abnormal phenomenon or problem, please switch off the power supply then contact with Genice customer service center.

Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving

Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving



Round 200 w Industrial High Bay Led Lighting 130lm/W For Warehouse , Energy Saving









Trade terms



Payment : T / T , western Union or Paypal


Shipping : By Express ( EMS , DHL , UPS etc ) , By Air or By Sea


Delivery time : 7 - 15 working days for normal orders


Port : Shenzhen , China



Our service


1. Your inquiry for our products will be replied in 24 hours


2. Well-trained and experienced staffs to answer all your enquires in fluent English


3. OEM and ODM are welcomed


4. Make the products as your requirement.


5. Protection of your sales area , ideas of design and all your private information
