100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly

Good quality High Power LED Flood Light for sales
Good quality High Power LED Flood Light for sales
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly

China 100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly supplier
100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly supplier 100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly supplier 100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly supplier 100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly supplier

Large Image :  100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly

Product Details:

Place of Origin: China
Brand Name: Leyond
Certification: CE RoHS
Model Number: LY - HB35100

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Packaging Details: 3pcs/ctn
Delivery Time: 7-10 working days
Payment Terms: T/T, Paypal
Supply Ability: 3000pcs per month
Contact Now
Detailed Product Description
Item: LED UFO High Bay Lamp Power: 100W
Inptut Voltage: AC100V ~ 240V 50 / 60HZ LED Driver: Meanwell HLG
Bean Angle: 120° CRI: >80
Warranty: 5 Years Warranty Lamp Driver: Or Meanwell

50w 100w 150w 200w LED high bay UFO warehouse light

Facture:



Up to 80% Energy-saving compared to metal halide lamp , mercury-free and 100% recyclable,

energy saving and environmental protection



Isolated internal led driver , easy installation , safety guaranteed



High PF value 0.9 above and THD less 15% for decrease of electricity loss



Up to120LM/W high light efficacy , 50000h above lifespan , 5 Years warranty , cost effective



Power supply key components adopt world brand , No flicker , no delay , Instant on / off



Designed for hook type , can be directly replaced is used to quick and easy



Installation to minimize retrofit and maintenance costs



Small size , less weight and durable is the best choice for warehouses , stadiums , exhibition spaces , high ceiling lights.



Using imported chip , LED encapsulation structure optimization , to achieve low light failure , high photosynthetic efficiency , energy conservation and environmental protection advantages.​

  • Technical parameter
Par NO Parameter
LY-HB35100WW
LY-HB35100NW
LY-HB35100PW
Inptut voltage
AC100V~240V 50/60HZ
Sysem consumption(W)
≤102
≤102
≤102
Light Fixture Luminance(lm)
10900
11600
12100
LED type
SMD3030
SMD3030
SMD3030
LED QTY
120
120
120
System Efficiency
>90%
>90%
>90%
Driver
/ MEAN WELL
Beam Angle
120°
120°
120°
CRI
>80
>80
>80
Color Temperature(CREE)
2700-3200k
4000-4500k
5000-6500k
Meterial
Magnesium Aluminum + PC cover
Lifespan(hrs)
>50000
IP Rating
IP65
Product Size(mm)
Φ340X162
Φ340X162
Φ340X162
NET Weight(KG)
3.6
3.6
3.6




100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly

  • Distribution Curve

100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly



Application



There is widely used in Warehouse , Industrial workshops , Logistics centers , Exhibition halls , Stadiums , Docks , Golf courses , Airport , Highway toll stations , supermarkets Light engineering.



100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly





Package



  • Carton Size: 370mm×370mm×180mm
  • Net weight:3.6KG Gross weight:4.5KG



100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly







Assembly and Installation



  • Assembly Electricity

100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly

  1. Blue : Neutral
  2. Brown : Line
  3. Yellow-Green : Ground



  • Installation



Step1. Ensure all power disconnected and turn off the power switch.



Step2. Knowing the inside diameter of the circular ring,then choose suitable hook for the lamp.



Step3. Fix the hook before installation and enable it to support over 3 times weight of the lamp. Connect the lamp with hook and make it safe.



Step4. Connect the input cables of lamp to power supply mains and wrap up the cables with insulated sleeve.



Step5. Switch on the power, the lamp will light on. Refer to the left figure.



In case of any abnormal phenomenon or problem, please switch off the power supply then contact with Genice customer service center.



100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly









Trade terms



Payment : T / T , western Union or Paypal


Shipping : By Express ( EMS , DHL , UPS etc ) , By Air or By Sea


Delivery time : 7 - 15 working days for normal orders


Port : Shenzhen , China



Our service


1. Your inquiry for our products will be replied in 24 hours


2. Well-trained and experienced staffs to answer all your enquires in fluent English


3. OEM and ODM are welcomed


4. Make the products as your requirement.


5. Protection of your sales area , ideas of design and all your private information



100 W High Bright Led High Bay Shop Lights IP65 Outdoor With PC Cover , Eco Friendly
