150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty

China 150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty supplier
150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty supplier 150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty supplier 150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty supplier 150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty supplier

Large Image :  150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty

Product Details:

Place of Origin: China
Brand Name: Leyond
Certification: EMC,LVD,RoHS
Model Number: LY-HB55150-XX

Payment & Shipping Terms:

Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: Standard Plain Carton
Delivery Time: 5-15 workdays
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 30,000 pcs/month
Contact Now
Detailed Product Description
Power: 150w LED Chip: Lumileds 3030 Chips
LED Driver: Meanwell / Sosen CCT: 2700-6500K
Beam Angle: 120 Degree Material: Aluminum+PC Optical Lens
CRI: >70 Lumens: 18300 Lm



Newest Design Low Bay Light V2 150W Lumileds Chips & Meanwell Driver 5 Years Warranty



Specification:

Product Model Power LED Quantity Luminous Flux Light Efficiency CRI CCT Beam Angle
LY-HB55150-XX    150W     210pcs   18300 LM 122 LM/W  >70 2700-6500K   120°



Product Model Input Voltage Product Size IP Grade Life Span Material Power Range
LY-HB55150-XX AC100-240V 362X291X130mm IP50 50,000 hrs Alumium+PC 150/200/240w



Model Inptut voltage Luminous Flux LED type LED QTY System Efficiency
LY-HB55150PW AC100V~240V
50/60HZ
15800lm LUXEON 3030 200PCS >90%
LY-HB55150WW 14000lm
LY-HB55150NW 14550lm




Advantages:

Low Bay Light with  chips& Meanwell driver,5 years warranty.


1) Perfect mounted in high location on warehouse/parking place/workshop,etc.
2) Lumileds chips plus Meanwell driver, UGR:18, 5 years warranty.

3) 1-10V Dimmable and microwave motion sensor both available.
4) Lock catch and chain as standard equipped for installation.

Application:

l It is applicable to Indoor Stadium lighting ,warehouse lighting, Workshop lighting,
factory lighting,Supermarket lighting and so on.
l New Installation or Replace the traditional High Pressure Sodium Lamp, High Pressure
Mercury Lamp, and Metal Halide Street Lamps. Etc.

Our Service:
Payment: T/T in advance
Items: EXW Price
Delivery Time: 5-7 days for sample, 12-18 work days for bulk order.
Shipping way: DHL, FEDEX, UPS, TNT express, by sea or by air.





Quality Control:

Quality guarantee is based on storing,installing,operating and maintaining correctly in the normal operation condition.

It is not included in our maintaining range when installing inappropriately,breaking the operating rules,and leading to the products damaging.

Our company will maintain the right to either repair,parts replacing,or products exchange during the quality warranty period.



Operation and Storage Condition
1) Operation Ambient Temperature -20 to +50°C, Relative Humidity 20~90%
2) Input Voltage 100~240V AC, 50/60Hz
3) Storage Ambient Temperature -20 to +65°C, Relative Humidity 5~95%
4) Mounting Height : Suitable for 5~12m height.

150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty

150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty

150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty




150W Newest Design Low Bay Light Lumileds 3030 Chips Meanwell Driver 5 Years Warranty

Package



·Carton Size: 390mm×390mm×160mm





 3030 SMD Led Low Bay Lighting 150w 240w With Meanwell Elg Dimming Driver





Quality Control

100% of the lamps will be tested and keep lighting for 24 hours to test its quality reliability
and we will also test its temperature after 24 hours’ lighting. Then after it is cool we again test
100% of the lamps to see if it still work well . Each lamp should pass all these QC procedures
before shipping to customer.
