Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof
Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof

Large Image :  Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof

Product Details:

Place of Origin: China
Brand Name: LEYOND
Certification: CE, LVD, EMC,RoHS
Model Number: LY-HB38240-XX (XX for CCT)

Payment & Shipping Terms:

Minimum Order Quantity: 2pc
Price: Negotiable
Packaging Details: Plain brown carton packing/customization available
Delivery Time: 7-10 working days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 20,000Pcs/month
Detailed Product Description
Power: 240w (100w,150w,200w Available) Input Voltage: AC100-240V
LED Brand: Lumileds 3030 Chips Driver: Meanwell HBG Series
IP Rate: IP65 Protection Beam Angle: 60/90/120d
CRI: >80 Warranty: 5 Years
High Light:

led high bay lamp

,

high bay led lighting

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof



240W UFO High Bay Light Features:

1) UFO design, lighter and nicer. Best for industrial lighting.(such warehouse,stadiums etc.)

2) Brand Lumileds 3030 chip inside. High lumens output>120lm/w for whole lamp.

3) Top class Meanwell driver, high efficency. PF>0.95.

4) Rugged die-casting aluminium alloy body coated with black anti-corrision coating, excellent heat dissaption.

5) High brightness,luminaire 130lm/w, 100w/150w/200w/240w for application.
6) 60 /90 /120 degree beam angle for optional, light weight, easy assembly & installation.



Parameter

Part No. LY-HB38240-XX (XX for CCT)
Power 240watts
Inptut voltage AC100V~240V 50/60HZ
Lumens 29300lm
LED Source SMD3030
LED QTY 360pcs
LED Driver / MEAN WELL Brand
Beam Angle 60/90/120degree
CRI >80
Color Temperature 2700-3000K,4000-4500K,5000-5700K
Meterial Magnesium Aluminum + PC cover
Lifespan(hrs) 50,000hrs
IP Rating IP65 Protection
Product Size(mm) Φ400X204
NET Weight(KG) 5.0KG
Warranty 5 years



Pictures:

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 0

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 1

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 2

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 3

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 4

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 5

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 6

Aging Test:

100% of all lamps will be tested by auto testing line which including different voltage, and keep lighting for 24 hours to test its quality reliability and we will also test its temperature after 24 hours’ lighting. Each lamp should pass all these QC procedures before shipping to customer.

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 7Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 8Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 9

Instatllation Guide:

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 10

Application:

The lamp can be widely used in Warehouse,Industrial workshops,Logistics centers,Exhibition halls,Stadiums,Docks,Golf courses,Airport,Highway toll stations,supermarkets Light engineering.

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 11

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 12

Robust housing LED HighBay Light Lumileds 3030 Chips,CRI >80,IP65 waterproof 13

FAQ:
1. What is your price?
---Based on your quantity and specification requirement, reasonable and affordable price.


2. How many years warratny?
---5 years warranty, 50000 hours lifespan.


3. What is the payment term?
---For sample order, we can accept T/T, Paypal, West Union, 100% in advance.

For bulk order, 30% deposit in advance by T/T, 70% balance before shipping.


4. What's your fast delivery time for sample 1-10pcs?
---Within 2 day once receive your payment.


5. Can I add my Logo on the product label?
---Yes.


6. I don’t know how many Led High Bay Light should I use, can you advise?
---Yes, we can help you do the lighting design using software Dialux, IES file is available if you have the design team.



7. How many years are you do led lights business?

---10 years experiences since 2007.
