AC100-240V 100W led flood light with IP66 waterproof rating.

small.img.alt small.img.alt

Large Image :  AC100-240V 100W led flood light with IP66 waterproof rating.

Product Details:

Place of Origin: China
Brand Name: Leyond
Certification: CE,ROHS&ISO
Model Number: LY-FL39100XX

Payment & Shipping Terms:

Minimum Order Quantity: 8pcs
Price: Negociatable
Packaging Details: carton box package
Delivery Time: 5-12 working days
Payment Terms: T/T, Western Union or Paypal
Supply Ability: 6000pcs/month
Detailed Product Description
Flatpad LED Flood Light: 100W LED Luminous Efficiency: >= 1200m/W
CRI: >70 Beam Angle: 120º
Bridgelux Chip: Meanwell Driver LED Chip: Lumileds Luxeon 3030
High Light:

led outdoor flood lights


outside led flood lights

AC100-240V 100W led flood light with IP66 waterproof rating.


1, Features:
Full waterproof design
High transmittance empered glass,transimittan 93%
The radiating area 4260cm²
Multi-Chip on lead frame,single module LED package design
System design integrating power supply,LED light engine ,and heat sink
Over Current,Over Voltage,Over Heat,Thunder Protection
Choice of correlated color temperatures
Long lifespan for LED 50,000 hrs
Complying with CE,ROHS, No strobing during working, Fast response (no delay) , No

mercury vapour ,No radiation,No UV,No damage with frequency switching
IP Rating: IP66
Power supply direct touch the radiator,in light weight


2,Application area:
Replacing traditional High Pressure Sodium lamp or metal halide lamp.
Widely used for advertise billboard ,exterior wall of hotel and related landscape lighting


3,Product Dimension:


AC100-240V 100W led flood light with IP66 waterproof rating. 0



1,All dimension units are millimeters.

2,All dimension tolerance is ±1mm unless otherwise noted.


4,Product Specification:

Input voltage: AC100V~240V
Freqency range: 50HZ~60HZ
Tatal harmouic distortion: ≤9%
Power facor:  ≥0.9
Power efficiency:  >85%
Sysem consumption: 100W

LED package: Multi-chip on led frame,Single module
LED consumption: 100W
LED Working voltage: DC30~36V
LED quantity:1PCS
LED luminous: >12000 lm
LED luminous efficiency: 110~120 lm/W
CRI: >70
Facula area:
H=6m 12m×12m
H=8m 15m×15m
H=10m 18m×18m
Illuminance uniformity: >0.68
LED Junction temperature: ≤60℃
Operational condition: Temperature -30℃~60℃
Humidity  10%~90%RH
Storage temperature: -40℃~85℃
Working life-span: >50,000H
Connect wire: Brown-L Blue-N Yellow/Green-G
Beam angle: 120°
IP Grad: IP66
Housing:  Aluminum
Mounting Height: Suitable for 8~10m height

5,Connect wire:




AC100-240V 100W led flood light with IP66 waterproof rating. 1

1 Carton = 1 Set Size: 510mm×430mm×135mm  5.6Kg


Installation tool:  A adjustable wrench group.
Installation Steps:
① Tighten Axle Screw, and Locate Screw
② Connecting the power line of LED Flood Light to the power supplier ,finish the installation procedure
The installation notices:
① No necessary using other devices for LED Flood light installation such as stabilizer,  regulator and so on
② Opening the light and lifting the buckle is unallowable. Soaking in the  water is unallowable


Do Not Use Other Devices for LED Floodlight Installation Such as Stabilizer,
Regulator …etc
Do Not Open the Light Engine
Do Not Soak the Floodlight into Water
Do Not Light up the System Without Grounding
Do Not Use Dimmer



3 Years Warranty Starts from Taking Delivery of Goods a Day. The Warranty Content
Includes the Damage of All Components, Such as LED Light Source and Power


The Floodlight Must Operate at the Common Normal Environment. As in Order to
be Faced by the Sea Road in 3 Kilometers or to Use in the Bad Environment Such       as Tunnel, Warranty Period is Within 1 Year.

The Calculation of Warranty Period with Turn on the Light for a Day 8-10 Hours is Limited. As Everyday Longer Than 10 Hours, Then Gradually Decrease According to Comparison Warranty Time Limit.
