Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control

Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control
Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control

Large Image :  Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control

Product Details:

Place of Origin: Shenzhen of China
Brand Name: Leyond
Certification: CE,ROHS,LVD,EMC
Model Number: LY-ST20150PW

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: please contact us
Packaging Details: Foam inside,1pc per box, 2 boxes per carton
Delivery Time: 2-5 working days for samples, 7-20 working days for bulk orders
Payment Terms: T/T, Western Union,Paypal etc
Supply Ability: 10000pcs/month
Detailed Product Description
Housing Color: Black Wattages: 30W-150W
Light Efficiency: 160lm-170lm/w LED Chip: /Bridgelux
Driver Brand: Meanwell Driver Size Of Product: 642*200*120mm
Warranty: 5 Years IP Rate: IP66
Lamp Body Material:: Aluminum Working Temperature(℃):: -40 - 50
High Light:

outdoor led street light

,

led street lamp





Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control



150W Sword LED Street Light , IP66,Black or Grey Die Casting Aluminum Housing with Meanwell + Chips





Specification :


Item Number LY-ST20150PW
LED Power 150W
Input Voltage Meanwell  AC100-240V
LED Chip 3030 LEDs
LED Quantity 180pcs
Lumen 24000-25500lm
Power Factor >0.95
Efficiency >90%
Beam Angle horizontal 150deg, vertical 65deg
Color Temperature 2800-3000K (WW);  4000-4500K(NW), 5000-5500K(PW), 6000-6500K (CW)
Guard Level IP66
Lifespan 50,000hrs
Housing Material Aluminum Alloy
Product Dimension 642x290x120mm
Net Weight 8.8kg
Gross Weight 9.6kg


Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 0





Application :



Suitable for the street lighting at highways, urban roads and secondary roads, stadiums,
sidewalks, residential areas, industrial areas, squares, parks, schools, villas, gardens and other places.



Features :



-          High Lumens output >160lm/W, with Bridgelux chip high power LEDs



-          With asymmetric optic lens, higher lumens transmittance up to 98%



-          Meanwell brand driver HLG series, input voltage AC100-277V, PF>0.93



-          Popular LED modules inside, easier for maintanance



-          Duct type thermal design, reduce the weight of the light and ensure good heat dissipation



-          Durable lights with long life span 50000 hours, 5 years warranty



-          Nice appearance with waterproof IP rating: IP66



-          Matching 3x1mm² silicon rubber cable 1 meter (customize available)



Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 1

Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 2



Intensity Distribution Diagram :



Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 3

Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 4



Aging Testing :



As we know aging test is a critical insurance of the quality for led lights, so recently we just

introduced the auto aging test equipment which can make the test more accurate and effective .

More info as belowing :



Voltage testing

High,normal,low voltage testing

Temperature testing

High temperature

Lighting testing

ON and OFF testing

Moving testing

Base plate will recycle times and times

City power testing

Simulate the city power



Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 5



Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 6

Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 7



Packing :



Ik08 IP66 Dimming High Power Led Street Light Lamp Sensor Smart Control 8



Our services :



1.Factory price, large monthly output

2. 5years warranty, high quality guarantee

3. professional Export service, easy to communicate and save your much time

4.Timely delivery, let you win biggest markets advantage

5.Satisfied After-sales service, to be your reliable supplier

6. any question will be get answer within 12 hours

7. R & D team, welcoem OEM and ODM order



FAQ:



1. How to choose LED light source?

A: Lumens(LM), light efficiency (LM/W), Life span (hrs) are very important factors when choosing LED light source. The higher, the better. Besides, brand of LED chip, LED base and other materials will influence the product reliability.



2. Why choose Leyond Lighting?

A: Client-oriented, technology first, hornest operation is our business philosophy. Leyong always treat the clients benefit as the most important thing. So, we use the top brand material to produce high quality product.



3. What can Leyond offer?

A: Our products covers a wide range. We can offer you, LED flood light, LED high bay, LED downlight, LED ceilling light, LED spot light, LED tube, LED module, LED Street Light, ect.



4. How to place an order?

A: Contact our sales representatives by email, skype or making a call, we will soon send you confirm with you for your detailed requirements. Then we send you PI for your approval and payment. You can choose wire transfer, PayPal, west union to send us payment.



5. How long will be the lead time?

A. This will be subject to your order quantity. Normally, below 5,000pcs, we will deliver within 15 working days. For large quantity, please confirm with your order.



6. How long will the warranty period last?

A: We usually offer 3 years free warranty for Bridgelux products. More detailed warranty policy, please contact our sales representatives.
