Product Details:
Payment & Shipping Terms:
|
| Lamp Body Material: | Aluminum+PC | Power: | 50w |
|---|---|---|---|
| IP Rating: | IP65 | Warranty: | 5 Years |
| LED Light Source: | Bridgelux | Beam Angle: | 150*70 Degree |
| Lamp Luminous Flux(lm): | 6000 | CCT: | 2700-3000K 4000-4500K 5000-6500K |
| Highlight: | led roadway lighting,led street lamp |
||
Ip65 50 Watt Street Lighting Led Street Module 120lm / W LED Module
LED Module Details:
Specifications
| Power: | 50w |
| Material: | Aluminum Alloy/PC |
| Chip: | Bridgelux 23*45mil |
| Luminous: | 6000 LM |
| Color Temperature: | 2700 ~ 6500K |
| CRI: | Ra 50/60/70(optional) |
| Beam Angle: | x150° ~ y70° |
| PF: | >0.95 |
| Working Life: | ≥ 50000 hrs |
| Warranty: | 5 years |
| Dimensions | |
| Finishing Color: | Silver |
| Wire connection: | L(Brown);N(Blue);G(Green/Yellow) |
| SHAPE: | Rectangle |
| Package: |
10pcs/carton |
| Application | |
| Application: |
Used for highway, main road, pavement street, residential road, branch road,rural roads, Square,Parking lots, Gardens, Industrial roads, and indoor high space lighting,factories. etc |
| Recommend mounting height: |
8m-12m |
Housing:
6063 aluminum housing.
Fin heat sink to ensure maximum heat transfer
LED & Optical Assembly
Precision refractive optical lens special designed for road lighting.
Utilizes high brightness leds , 70 CRI at 5000-6000K
Rating
Suitable for wet locations.
IP67 rated optical enclosure.
Temperature Rated at –30° to 50°C.
Contains no lead or mercury
Advantages:
1. Convection heat radiation design, deduce light decay and prelong life span, CHEM module, easy replacing.High luminous efficiency
2. 30PCS Bridgelux LED inside,High efficiency.
3. Adoption patent optical lens with high light transmittance up to 98%,No glare,No RF interference.
4. Excellent heat dissipation design.
5. Easy to assemble and costs less for replacing.
6. Total Lumen 6500-7000LM,lumens efficiency is up to 150/W.
7. Convection heat dissipation system ensure LED long life span.
8. Several led chips available, easy selection with your goal.
9. Unique aluminium heatsink greatly reduce product weight and guarantee the safety usage
10. This new heatsink significantly increase the efficiency of thermal conduction with less material usage and more saving on energy. It is the best solution of LED street light.
Our service
1. Your inquiry for our products will be replied in 24 hours
2. Well-trained and experienced staffs to answer all your enquires in fluent English
3. OEM and ODM are welcomed
4. Make the products as your requirement
5. Protection of your sales area, ideas of design and all your private information
Trade terms
1. Payment terms:30% of all value paid by T/T as deposit, the balance paid before loading
2. Lead time:7 working days for samples ; 7-15 working days for bulk order
3. Packaging:Standard exporting package, also can be customized according to your requirements for Logo,Brand,etc
4. By UPS/DHL/FEDEX/TNT:It takes 3- 5 days to arrive the destination
5. Air cargo: It takes about one week to arrive the destination
6. Sea shipment: It takes about one month to arrive the destination, depending on your actual requirements
