100W 120W 150W energy saving high bay lighting With 5 Years Warranty

100W 120W 150W energy saving high bay lighting With 5 Years Warranty
100W 120W 150W energy saving high bay lighting With 5 Years Warranty

Large Image :  100W 120W 150W energy saving high bay lighting With 5 Years Warranty

Product Details:

Place of Origin: China
Brand Name: LEYOND
Certification: CE RoHS
Model Number: LY-YL20100PW

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: 75-80 USDnegotiate
Packaging Details: Standard export package, 1pcs/ctn
Delivery Time: 7-10 working days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 5000pcs per month
Detailed Product Description
Power: 100W / 120W / 150W Voltage: AC100v ~ 240v 50/60HZ
Bean Angle: 90° Driver: Meanwell/INVENTRONICS Driver
Chip: Lumileds 3030 /5050 CRI: >80
IP Grade: IP65 CCT: 2700K - 6500K
Material: PC Reflector/PC Lens
High Light:

led high bay lamps

,

led high bay lamp

100W 120W 150W energy saving high bay lighting With 5 Years Warranty



1. Features

Using LUXEON 5050 led chip to ensure high lumen and long life. Whole lamp output light efficiency >160LM/W.

Adoption LEYOND exclusive Lens with light transmittance up to 98%.

Seals using silicone rubber, oil proof, aciduric, alkali fast, fire resistant.The unit construction of lamp adopt waterproof and dust proof design, It can meet the indoor and outdoor needs .

Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the

brightness and illumination uniformity.

There are 95°beam angle for your optional, optimized light distribution design solution.

High luminous efficiency, High quality power supply, input voltage 100-240V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.

The whole lamp with the powder coating is brighter, without fading and corrosion.

Impact Resistance, Shock-proof, Without Ultraviolet (UV) and Infrared (IR) Radiation: No filament and glass frames, avoid break of the traditional lamp,without harm to the human body.

The CCT of Warm white,Neutral white,Pure white to meet the needs of different occasions, eliminated the low color temperature of the sodium lamp which cause the depressed mood, observers will feel more comfortable.



2. Specificate



Par NO

Parameter

LY-YL20100PW LY-YL20100WW LY-YL20100NW
Input voltage AC100V~240V 50/60HZ

System

consumption(W)



100



100



100

Luminous flux(lm) 16000 14000 15500
Chip Brand

LUXEON 5050/LEYOND 5050

LUXEON 5050/LEYOND 5050

LUXEON 5050/LEYOND 5050

Color Temperature Pure white:5000-6500K Warm white:2700-3200K Neutral white:4000-4500K
CRI >70
Beam Angle 85 DEG
LED Driver MEAN WELL ELG-100 / XLG-100

Luminous

efficiency(lm/w)



>160

Lifespan(hrs) >50000
IP Rating IP66
Dimmable YES&NO YES&NO YES&NO
Size(mm) 383x383x61 383x383x61 383x383x61
Net Weigh(kg) 5.8 5.8 5.8
Package Size(mm) 428*428*125 428*428*125 428*428*125
Package Quantity(Pcs) 1 1 1
Gross Weigh(kg) 6.6 6.6 6.6



3. Product Details:



Ant -Glare 100W 120W 150W Ceiling Mounted Canopy Gas Station Workingshop Lights



100W 120W 150W energy saving high bay lighting With 5 Years Warranty 0

Mounting with Handle

STEP1:
First check if the site can afford the weight of more than 1.5 times of the light. If not,please do not install.
STEP2:
Install the LED modular Light onto the wall or the lampposts:punch hole on the wall or lampposts, prepare the expansion screw ,and then fasten the LED modular Light .
STEP3:
Remove the hexagonal screws on the LED modular Light handle,then adjust the angle you need,finally fasten the LED modular Light with the screws.
STEP4:
The ex-factory of the standard components of the LED modular Light include a 3*1mm2 cable. Connect the wires correctly.
STEP5:
Switch on the power and make sure the light is on.Then the installation is done.

100W 120W 150W energy saving high bay lighting With 5 Years Warranty 1

Mounting with Pipe

STEP1:
Feed the luminaire leads through the Stem and attach Stem to luminaire by threading the stem into the threaded hub.
STEP2:
Assemble the junction box to the Stem by placing one of the conduit nut onto stem.
STEP3:
Loosen,do not remove,junction box screw and flflip junction box cover up.Place the junction box onto the stem.
STEP4:
Place the second conduit nut on to the stem from inside The junction box and tighten the nut.
STEP5:
Connect the wires correctly and make sure the good wire protection.
STEP6:
Sealed by water proof glue between fixture and pole.

100W 120W 150W energy saving high bay lighting With 5 Years Warranty 2



Surface Mounting

STEP1:
Openings one hole greater than 10-40mm through hole in the ceiling.
STEP2:
Put the fifixture on the ceiling, make four marks according to 4 mounting kits, then drill 4 holes for them.
STEP3:
Connect the wires correctly and make sure the good wire protection.
STEP4:
Get rubber plugs into the holes, match 4 mounting kits to the Rubber plugs, then fifix the fifixture on the ceiling by screws. Ensure that no wires are pinched during installation of luminaire.
STEP5:
After installation, sealed by waterproof glue between fifixture and the mounting surface.

100W 120W 150W energy saving high bay lighting With 5 Years Warranty 3



4. Distribution Curve





100W 120W 150W energy saving high bay lighting With 5 Years Warranty 4

100W 120W 150W energy saving high bay lighting With 5 Years Warranty 5




5. Operation and Storage Condition

Operation Ambient Temperature -25 to +50°C, Relative Humidity 20~90%

Input Voltage 100~240V AC, 50/60Hz

Storage Ambient Temperature -30 to +65°C, Relative Humidity 5~95%

Mounting Height : Suitable for 6~18m height





FAQ:

1. May I have a sample for the light please?
---Sure,we welcome sample test.

2. How many watts does this light provide?
---100w, 150w, 200w,250w

3. Which shipping way do you have?
---DHL, FEDEX, UPS and TNT are all support. By sea or by air can be available based on your request.

4. How many years warranty will you provide?
---5 years warranty.

5. What is the delivery time?
---Normally, 5-7 days for sample, 15-20 days for bulk order. If on special condition, the delivery time can be discussed.

Thanks for your time! Warmly welcome to inquiry our sales team for further information. Specification, pricelist and dialux simulation could be provide if need!
