Product Details:
Payment & Shipping Terms:
|
Power: | 150W | LED Chip: | Lumileds |
---|---|---|---|
LED Driver: | Meanwell/Sosen/others | IP Rating: | IP65 |
CCT: | 2700-6500K | Material: | Die-casting Aluminum+PC |
Warranty: | 5 Years | Beam Angle: | 150X70degree |
Highlight: | led roadway lighting,led street lamp |
Features:
1. Absolutely unique mold,make your lighting special and fantastic.
2. Perfect Light Distribution Solution: Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.
3. Anti-glare and uniform light level to avoid any visual discomfort.
4. High quality power supply, input voltage 100-277V. The power efficiency is more than 90%, power factor
greater than 0.98, UL compulsory certification.
Specification:
Input Voltage |
100~240V AC,50/60Hz |
---|---|
Power Factor |
≥0.95 |
Power Efficiency |
≥88% |
Power |
30W/40W/50W/60W |
Luminous Efficiency |
≥110lm/W |
CRI |
>80 |
Beam Angle |
150*65° |
CCT |
WW:2700-3200K NW:4000-4500K PW:5000-6500K |
Operational Condition |
Temperature:-30℃~60℃ Humidity:10%~90%RH |
Model |
Power Consumption |
Current |
Product Dimension(mm) |
Luminous Flux |
IP Rating |
Net weight |
---|---|---|---|---|---|---|
LY-ST20030XX |
30W |
0.14A/220V |
410*200*90 |
3900 |
IP65 |
2.8 |
LY-ST20040XX |
40W |
0.19A/220V |
5000 |
|||
LY-ST20050XX |
50W |
0.24A/220V |
6100 |
|||
LY-ST20060XX |
60W |
0.29A/220V |
6100 |
Applications:
