Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road

Certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
Customer Reviews
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road

Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road
Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road

Large Image :  Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road

Product Details:

Place of Origin: Guangdong, China
Brand Name: LEYOND
Certification: CE RoHS
Model Number: LY-ST20150-XX

Payment & Shipping Terms:

Minimum Order Quantity: 2 pcs
Price: Negotiable
Packaging Details: Standard Export Packing
Delivery Time: 5-7 days for samples
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000 pcs/month
Detailed Product Description
Power: 150W LED Chip: Lumileds
LED Driver: Meanwell HLG-150 IP Rating: IP65
CCT: 2700-6500K Material: Die-casting Aluminum+PC
Warranty: 5 Years Beam Angle: 150X70degree
Package: 720*370*220 (2PCS/CTN) GW: 9.6kg
High Light:

outdoor led street light

,

led street lamp

Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road





Product Description:


1. Save 80% more energy compared with traditional lighting fixtures



2. Easy to install and use, secure and reliable



3. No UV or RF interference, No mercury or lead



4.Light body is made of good quality die casting aluminum, exiguity and unique design, excellent heat dissipation



5. long life span>50000hrs



6. High brightness, low consumption, green for environment



7. AC85-305V in different countries and regions.AC12/24V led driver is also available



8. Potection grade is IP65


Features:


1. Completely independent design, which include the heat sink, PC lens and frame. To make your product more unique and attractive. Meanwhile, the light source are package by our own factory. Quality controll will be more stable.


2. Adopt famous Lumileds 3030 chip inside, high efficiency can up to 120 lm/w.


3. Die-casting housings, streamline heat sink with good heat dissipation


4. Meanwell HLG driver and offer 5 years warranty. Price is more competative than others on the market.


5. Short lead time, sample is 3-5 days; Bulk order is 10-15 days based on quantity. To be your firm supporter.


6. Support Photocell sensor, Zigbee, solar systerm and 0-10V dimming, make the lamp smart and more energy saving.



Specification:


Model Inptut voltage Sysem consumption Luminous flux Chip Brand Beam Angle
LY-ST20150PW AC100V~240V
50/60HZ
150W 18750lm 3030 150*65°
LY-ST20150WW 17400lm
LY-ST20150NW 18000lm



Model CRI Color Temperature LED Driver Luminous efficiency Lifespan IP Rating
LY-ST20150PW >80 WW:2700-3200K
NW:4000-4500K
PW:5000-6500K
MEAN WELL
HLG-150H
>120lm/W >50000h IP65
LY-ST20150WW
LY-ST20150NW






Model Dimmable Size(mm) Net Weight Package Size(mm) Gross Weight
LY-ST20150PW YES&NO 642x290x120 8.8kg 720*370*200 9.6
LY-ST20150WW
LY-ST20150NW



Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road 0Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road 1



Application:

The street light can be widely used for the Highways, Urban Roads and Secondary Roads, Stadiums, Sidewalks, Residential Areas, Industrial Areas, Squares, Parks, Schools, Villas, Gardens and others lighting place.



Die-cast aluminum housing 100W 120W 150W Led Street Light For Highway And Road 2





Our Services:



MOQ: 2pcs



Port: Shenzhen, Zhongshan, Guangzhou



Sample availability: Yes



Supply capability: 1000 pcs/day



Payment: T/T, Western Union, Paypal.



Shipment: ocean or air transportation, international express



Normal lead time: 5days for sample order;10 days for production order



Payment condition: 30% before production, 70%before delivery





FAQ:

1. What is your price?
Based on your quantity and specification requirement, reasonable and affordable price.



2. How many years warratny?
   5 years warranty, 50000 hours lifespan.



3. What is the payment term?
For sample order, we can accept T/T, Paypal, West Union, 100% in advance.
For bulk order, 30% deposit in advance by T/T, 70% balance before shipping.



4. What's your fast delivery time for sample 1-10pcs?
   Within 2 day once receive your payment.



5. Can I add my Logo on the product label?
    Yes.



6. I don’t know how many Led Light should I use, can you advise?
Yes, we can help you do the lighting design using software Dialux, IES file is available if you have the design team.
