100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum

Certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
Customer Reviews
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum

100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum
100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum

Large Image :  100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum

Product Details:

Place of Origin: Guangdong, China
Brand Name: LEYOND
Certification: CE RoHS
Model Number: LY-ST20150-XX

Payment & Shipping Terms:

Minimum Order Quantity: 2 pcs
Price: Negotiable
Packaging Details: Standard Export Packing
Delivery Time: 5-7 days for samples
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000 pcs/month
Detailed Product Description
Power: 150W LED Chip: Lumileds 3030 SMD
LED Driver: Meanwell HLG-150 IP Rating: IP65
CCT: 2700-6500K Warranty: 5 Years
Beam Angle: 150X65degree Package: 75cm×40cm×23cm (2 PCS )
GW: 9.6kg Luminous Flux: 18750lm
Dimmable: YES&NO CRI: >80
Pole Diameter: 60mm
High Light:

outdoor led street light

,

led street lamp





Product Description:


1. Save 80% more energy compared with traditional lighting fixtures



2. Easy to install and use, secure and reliable



3. No UV or RF interference, No mercury or lead



4. Light body is made of good quality die casting aluminum, exiguity and unique design, excellent heat dissipation



5. Long life span>50000hrs



6. High brightness, low consumption, green for environment



7. AC85-305V in different countries and regions.AC12/24V led driver is also available



8. Potection grade is IP65





Features:



1. Absolutely unique mold,make your lighting special and fantastic.



2. Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.



3. Anti-glare and uniform light level to avoid any visual discomfort.



4. High quality power supply, input voltage 100-277V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.



5. Adopting 3030 led light sources and LEYOND lens technology, 8% light efficiency higher than the same type lights in the market, with higher light transmittance up to 98%.



6. Duct type thermal design, reduce the weight of the light and ensure good heat dissipation, lower luminous decay, and also extend life span of the leds. Adopting the popular CHEM modular design, effectively reduce the following maintenance cost.



7. Low energy consumption,matching high efficiency constant-current driver, 60% energy saving; with good resistance to over-current, over-voltage, lightning, high temperature, which fully ensure long life span and high stability of the products.



8. Durable lights with long life span up to 50000 hours; No need frequent replacements of lights and regular maintenance.



9. Green environmental protection, no UV light and infrared radiation, no mercury pollution.

10 . Nice appearance and non-fouling properties, Protection class IP66.

Specification:


Model Inptut voltage Sysem consumption Luminous flux Chip Brand Beam Angle
LY-ST20150PW AC100V~240V
50/60HZ
150W 18750lm 3030 150*65°
LY-ST20150WW 17400lm
LY-ST20150NW 18000lm



Model CRI Color Temperature LED Driver Luminous efficiency Lifespan IP Rating
LY-ST20150PW >80 WW:2700-3200K
NW:4000-4500K
PW:5000-6500K
MEAN WELL
HLG-150H
>120lm/W >50000h IP65
LY-ST20150WW
LY-ST20150NW






Model Dimmable Size(mm) Net Weight Package Size(mm) Gross Weight
LY-ST20150PW YES&NO 642x290x120 8.8kg 720*370*200 9.6
LY-ST20150WW
LY-ST20150NW





Aging Test:


100W 120w 150w High Efficiency Commercial Street Lamps 130lm / W Die Casting Aluminum 0





Our Services:



MOQ: 2pcs



Port: Shenzhen, Zhongshan, Guangzhou



Sample availability: Yes



Supply capability: 1000 pcs/day



Payment: T/T, Western Union, Paypal.



Shipment: ocean or air transportation, international express



Normal lead time: 5days for sample order;10 days for production order



Payment condition: 30% before production, 70%before delivery





FAQ:

1. How many watt you have for Sword led Street light ?

---- 30w, 40w, 50w, 60w 100w 120w 150w

2. How is the warranty?

----We could offer 5 years warranty, and during our warranty:

1). Products returned within the warranty period must be Leyond product number & date code.
2). Products of unknown sources or without valid marking will not be accepted.
3). Replacement items will be sent together with customer's next order shipment.

3. What's your delivery time?

---- For sample order our delivery time is 3-5 working days. For General order, for about 8 working
days.

4. What kind of payment and shippmeng do you use?
----T/T,Westen Union,Paypal
----Fedex,UPS,DHL,TNT,HongKong Post,EMS or other ways of shippment.


5. Would you do OEM or ODM orders?

---- Sure, OEM and ODM orders are welcome
