5050 SMD LED module street light high power led street lamp with CE RoHS CB certification

Certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
China Shenzhen Leyond Lighting Co.,Ltd. certification
Customer Reviews
I am very satisfied with your company in terms of quality.

—— Mr Frank

Hello Ada; I wish you have enoyed your holidays. Yes we tested the sample lamp, and we are very satisfy with the quality.

—— Ms.Valentina

I'm Online Chat Now

5050 SMD LED module street light high power led street lamp with CE RoHS CB certification

5050 SMD LED module street light high power led street lamp with CE RoHS CB certification
5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 5050 SMD LED module street light high power led street lamp with CE RoHS CB certification

Large Image :  5050 SMD LED module street light high power led street lamp with CE RoHS CB certification

Product Details:

Place of Origin: Guangdong, China
Brand Name: LEYOND
Certification: CE RoHS
Model Number: LY-ST20150-XX

Payment & Shipping Terms:

Minimum Order Quantity: 2 pcs
Price: Negotiable
Packaging Details: Standard Export Packing
Delivery Time: 5-7 days for samples
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000 pcs/month
Detailed Product Description
Power: 150W LED Chip: Lumileds 3030 SMD
LED Driver: Meanwell HLG-150 IP Rating: IP65
CCT: 2700-6500K Warranty: 5 Years
Beam Angle: 150X65degree Package: 75cm×40cm×23cm (2 PCS )
GW: 9.6kg Luminous Flux: 18750lm
Dimmable: YES&NO CRI: >80
Pole Diameter: 60mm
High Light:

outdoor led street light

,

led street lamp

Dia Casting Aluminum lamp body 100w 120w 150w led street lamp for highways high efficiency 130lm/w led street light



Features:



1. Absolutely unique mold,make your lighting special and fantastic.

2. Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.
3. Anti-glare and uniform light level to avoid any visual discomfort.
4. High quality power supply, input voltage 100-277V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.
5. Adopting 3030 led light sources and LEYOND lens technology, 8% light efficiency higher than the same type lights in the market, with higher light transmittance up to 98%.
6. Durable lights with long life span up to 50000 hours; No need frequent replacements of lights and regular maintenance.

Specification:


Model Inptut voltage Sysem consumption Luminous flux Chip Brand Beam Angle
LY-ST20150PW AC100V~240V
50/60HZ
150W 18750lm 3030 150*65°
LY-ST20150WW 17400lm
LY-ST20150NW 18000lm



Model CRI Color Temperature LED Driver Luminous efficiency Lifespan IP Rating
LY-ST20150PW >80 WW:2700-3200K
NW:4000-4500K
PW:5000-6500K
MEAN WELL
HLG-150H
>120lm/W >50000h IP65
LY-ST20150WW
LY-ST20150NW






Model Dimmable Size(mm) Net Weight Package Size(mm) Gross Weight
LY-ST20150PW YES&NO 642x290x120 8.8kg 720*370*200 9.6
LY-ST20150WW
LY-ST20150NW



5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 05050 SMD LED module street light high power led street lamp with CE RoHS CB certification 1



Aging Test:


100% of all lamps will be tested and keep lighting for 24 hours to test its quality reliability and we will also test its temperature after 24 hours’ lighting. Each lamp should pass all these QC procedures before shipping to customer.



5050 SMD LED module street light high power led street lamp with CE RoHS CB certification 2
