IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available
IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available

Large Image :  IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available

Product Details:

Place of Origin: Shenzhen
Brand Name: LEYOND
Certification: CE/ROHS/LVD/EMC ISO9001:2015
Model Number: LY-ST80050XX

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: USD50-USD100/PC
Packaging Details: KK cartoon + PE foam
Delivery Time: 7-15 working days
Supply Ability: 5000/Month
Detailed Product Description
Item Type: Street Lights Power: 50W
Lamp Luminous Efficiency(lm/w): 130LM/W Beam Angle(°): 150*85
Lamp Body Material: Aluminum+PC PCB: Aluminum 2MM
Led Light Source: Luxeon SMD3030 Application: ROAD, Outdoor, Highway, Garden, Courtyard
Warranty: 5 Years Certificate: CE ROHS ENEC
High Light:

IP66 50w LED Street Light

,

10KV 50w LED Street Light

,

IP66 LED Street Lights

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available



Leyond lighting IP66 Integrated alumin housing LED Street Lights 50W circuit switch 10KV SPD safety rope available



Specification



Par NO

Parameter

LY-ST80020XX LY-ST80030XX LY-ST80040XX LY-ST80050XX LY-ST80060XX
Input voltage AC100V277V 50/60HZ / DC12-24V
POWER(W) 20W 30W 40W 50W 60W
Luminous flux(lm) 3000 4440 5800 7150 8400
Chip Brand LUXEON 3030
LED Quantity (pcs) 72
Beam Angle TYPE III 150*80
CRI 70/80
Color Temperature Warm white:2700-3200K / Neutral white:4000-4500K / Pure white:5000-6500K
Luminous efficiency(lm/w) 150 148 145 143 140
LED Driver MEAN WELL / INVENTRONICS
Lifespan(h) 50000
IP Rating / IK IP66 / IK10
Material ADC 12
Dimmable 1-10V/DALI
Light body color Black/Grey
working environment Temperature -20 to +45°C, Relative Humidity 20~90%
Storage environment Temperature -20 to +60°C, Relative Humidity 5~95%
Size(mm) L580*W180*H106mm (L22.83*W7.09*H4.17Inch)
Net Weigh(kg) 3.5kg
Package Size(mm) L614*W222*H162mm (L24.17*W8.74*H6.38inch)
Package Quantity(Pcs) 1
Gross Weigh(kg) 4.3
Installation height(m) 4-8

Pictures

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 0

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 1

Application



Suitable for the street lighting at highways, urban roads and secondary roads, stadiums,sidewalk,

residential areas, industrial areas, squares, parks, schools, villas, gardens and other places.



IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 2

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 3



5. Features

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 4

1. The shell adopts die-casting integral molding, which has higher safety and longer life.

2. The product has a beautiful appearance and curved lines, which effectively reduces wind resistance;

3. The product has a smooth surface and self-cleaning function, which effectively reduces dust accumulation;

4. Using Philips 5050 lamp beads, the luminous efficiency is as high as 160lm/w

5. The optical lens adopts Japanese PC material, with a light transmittance of over 93%, anti-ultraviolet rays, and good product stability;

6. The lamp is equipped with a level gauge for positioning, which is more time-saving and beautiful in installation

7. Waterproof and dustproof grade: IP66, protection grade IK10;

8. The product is equipped with other more optional functions: light controller, circuit breaker,single lamp controller, anti-falling sling, etc.

6. Distribution Curve

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 5

7. Package

Inner box    L614.0*W222.0*H162.0mm    1pcs     2.5kg     3.3kg

Outer box    L632.0*W456.0*H348.0mm    4pcs     10.0kg     14.2kg

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 6

IP66 Integrated 50w LED Street Light 10KV SPD Safety Rope Available 7

8. Notes

This product provides a 5-year warranty period from the date of purchase.
During the warranty period, if the product fails under normal use, the company will
provide free maintenance services. During the warranty period, please strictly abide
by the product usage specifications:
1. Before use, please read the installation manual in detail for correct installation;
2. Please check carefully before use. If any abnormal phenomenon is found
during use, please keep the evidence and contact our company;
3. Please do not disassemble the lamp privately, otherwise it will be deemed to
automatically give up warranty.
