Product Details:

Place of Origin: China
Brand Name: Leyond
Certification: CE ROSH
Model Number: LY-HB56150PW

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: 330X328X100mm
Payment Terms: T/T, Western Union
Supply Ability: 10000PCS/month
Detailed Product Description
Power: 150W Input Voltage: 90-305V AC
Material: Aluminum + Pc LED Chip: Luxeon 3030 Led
Light Efficiency: 120-130lm/w PF: >0.95
CRI: >75Ra UGR: <19
High Light:

low bay led shop lights

,

led low bay lights

New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w



New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w 0

1. 150W LED Low Bay Light Specification

Model No. LY-HB56150PW LY-HB56150NW LY-HB56150WW
Inptut Voltage AC100-305V 50/60HZ
Power 150W 150W 150W
Luminous Flux 19500lm 18000lm 17500lm
Chip Brand LUXEON 3030 LUXEON 3030 LUXEON 3030
Color Temperature 5500-6000K 4000-4500K 2700-3200K
Luminous Efficiency >125lm/w >120lm/w >115lm/w
Power Factor >0.95
Beam Angle 120 DEG
LED Driver MEAN WELL ELG-150
Surge Protection 6KV
CRI >70
Lifespan >50000hrs
IP Rating IP54
Dimmable YES&NO
Size(mm) 330*328*100
Net Weight 5.3KG







2. 150W LED Low Bay Light Outlook

5-years warranty 240w led low bay light dimming warehouse lighting



3. 150W LED Low Bay Light Features
>>High power ,high brightness,high quality,high efficiency,up to 80% energy saving.
>>Light cover adpots light diffusion materials to bring us better lighting effect. High illumination, and the mliky cover can reach 90% light transmittance.
>>With low light degradation LED and good heat dissipation aluminum material with quick heat conduction. Make the LED lights have longer lifetime.10 times than the traditional ones.They need low cost in maintenance.So,they are fit for the lighting place where is hard to replace the broken lights often.
>>High luminous efficiency, whole lamp output light effiency >120LM/W.
>>High quality power supply, input voltage 100-305V. The power efficiency is more than 90%, power factor greater than 0.98, UL compulsory certification.
>>For the traditional light source such as the High Pressure Sodium, if the voltage fluctuation±7%, the brightness and lifetime will be reduced very fast, but for BBE LED, even the voltage fluctuation is ±20%, the brightness and lifetime will not be influenced at all; Over Current, Over Voltage, Over Heat, Thunder Protection.
>>Impact Resistance, Shock-proof, Without Ultraviolet (UV) and Infrared (IR) Radiation: No filament and glass frames, avoid break of the traditional lamp,without harm to the human body.
>>The CCT of Warm white,Natural white,Pure white to meet the needs of different occasions, eliminated the low color temperature of the sodium lamp which cause the depressed mood, observers will feel more comfortable.



4. Package

5-years warranty 240w led low bay light dimming warehouse lighting









5. 150W LED Low Bay Light Installation Instruction

5-years warranty 240w led low bay light dimming warehouse lighting



Carefully read the installation instructions and ensure the mains supply is isolated before installation. Please follow the safety information overleaf before carrying out any installation. Please retain this lealet for future reference.

Step 1:
Carefully remove the Low Bay and chain from the packaging. Install the chain onto the eye bolts on the back of the Low Bay light.

Step 2:
Mount the Low Bay light to the ceiling using a mounting hook and suitable suspension kit.

Step 3:
Secure the supply cable using suitable clips. Ensure that the cable is not touching the body of the Low Bay light .

Step 4:
Connect the cable to the mains as per the illustration below



6. Assembly-Electricity

5-years warranty 240w led low bay light dimming warehouse lighting



More detailed product information, please visit our website: www.leyond.com.cn

Any questions, pls feel free to contact us, LEYOND sales team will contact you soon.





Detail Pictures:



New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w 5

New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w 6

New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w 7

New design factory using 5 Years Warranty led low bay light with Luxeon 3030 led system efficiency 120lm/w 8

Company Information

5-years warranty 240w led low bay light dimming warehouse lighting5-years warranty 240w led low bay light dimming warehouse lighting5-years warranty 240w led low bay light dimming warehouse lighting5-years warranty 240w led low bay light dimming warehouse lighting5-years warranty 240w led low bay light dimming warehouse lighting5-years warranty 240w led low bay light dimming warehouse lighting

5-years warranty 240w led low bay light dimming warehouse lighting

FAQ

Q1. What is your MOQ?

MOQ: 1 Pcs. Which is No MOQ.



Q2. Can I get a lower price for large quantity order?

Yes, please check with our sales staff for the details.



Q3. What is the payment terms of your formal order?

We accept payment via TT, Paypal, Western Union, and we offer EXW terms.



Q4.Can you guarantee the product quality?

We offer 3-10 years warranty to our products. We ensure and guarantee the production quality of all products, either sample order or formal order, with LEYOND's quality control process, we achieved less than 0.2% general failure rate, this was based on our sales records in the past 10 years.



Q5. Can you provide OEM and ODM service?

Yes, we can provide OEM and ODM product, with customized label design on the product and carton box. Or customized carton box, and laser print logo on the lamp fixture.



Q6. Can you provide the certificate and test reports?

Yes, please contact our sales staff, we can provide all the certificates, test reports, photometric reports and IES files of each of our luminaire.



Q7.How do you ship the goods and how long does it take to arrive?

We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q8.What is the lead time of your product?

Our standard lead time for sample is 3-5 days, and normal order lead time is 7-10 days. For the large order lead time, please also check with our sales team.
